Zeyi-D-PRO

Item

Specification

DH5-PRO

DH5.7-PRO

DH6.67-PRO

DH8-PRO

DH10-PRO

Module     Parameter

Pixel Pitch(mm)

5

5.7

6.67

8

10

Pixel Structure

1R1G1B
 (Common Cathode)

1R1G1B
(Common Anode)

Pixel  Density(dot//m²)

40,000

30,772

22,477

15,625

10,000

Module Size(W*H)(mm)

480*320

480*320

480*320

480*320

480*320

Backshell Material

Die Casting Aluminum

Module Resolution(W*H)(dot)

96*64

84*56

72*48

60*40

48*32

Maximum Current(A)

9+13

9+13

9+13

9+13

9+13

Supply Voltage(V)

3.2+4.2

3.2+4.2

3.2+4.2

3.2+4.2

3.2+4.2

Scanning Method

1/8

1/7

1/6

1/5

1/4

Refresh Frequency(Hz)

≥1920

≥1920

≥1920

≥1920

≥1920

IIlumination(cd//m²)

5000~5500

5500~6000

6000~6500

Driver IC

Constant Current Drive

Contrast Ratio

≥5000:1

Cabinet Parameter

Cabinet Size(W*H*D)(mm)

960*960*83

Cabinet Material

Profile Aluminum

Cabinet Weight(kg)

27

Enclosure Connection Method

Screw Fixing

Installation/Maintenance Methods

Front and rear installation/front maintenance,optional rear maintenance

Color Temperature

/Luminance Uniformity

3200-9300K Adjustable,≥98%

Chromatic Uniformity

±0.003Cx,Cy

Horizontal/Vertical View

≥140/≥120°

Single-point Color Correction

Available

Single Point Brightness Correction

Available

Standard Receiver Card

A5S plus

Frame Rate(Hz)

50/60

Protection Level

IP65

Signal Interface Mode

RJ45

Power Interface Method

Connector

Input Voltage Range AC(V)

100-240

Peak Power Consumption(W/m²)

≤620

Average Power Consumption(W//m²)

≤310

Working Temperature and

Humidity Range

-20℃~+50℃,10%～95%RH

Storage Temperature and Humidity

Range

-40～+70℃,10%～95%RH

Service Life(H)

≥100000

Mean Time Between Failure(H)

≥10000
