No. | Item | Technical Parameters |
|---|---|---|
1 | Pixel Composition | 1R1G1B LED (SMD1415) |
2 | Pixel Pitch | 2.5mm |
3 | Module Size | 200mm*200mm |
4 | Module Resolution | 80×80 |
5 | Overall Screen Resolution | 240×320 |
6 | LED Packaging Manufacturer | NationStar, Jingtai |
7 | Total Pixels per Screen | 76,800 pixels per unit |
8 | Maximum White Balance Brightness | 5000cd/㎡ |
9 | Gray Scale Level | 12-16 bits |
10 | Display Colors | 281 trillion |
11 | Defective Pixel Rate | ≤0.0001 |
12 | Optimal Viewing Distance | 3m |
13 | Viewing Angle (H/V) | Horizontal: 120°; Vertical: 120° |
14 | Scanning Mode | 1/20 scan |
15 | Control System | Nova Asynchronous Control System |
16 | Frame Rate | 60Hz |
17 | Refresh Rate | 3840Hz |
18 | Screen Service Life | 100,000 hours |
19 | Overall Screen Weight | 15KG |
20 | IP Rating | IP65 |
21 | Working Voltage | AC 100/240V ±10%, 50Hz/60Hz |
22 | Ambient Temperature / Humidity | Temperature: -20℃～+60℃, Humidity: 10%-95% |
23 | Power Consumption (Max/Average) | Approx. 300W/unit / Approx. 100W/unit |
24 | Maintenance Method | Rear maintenance |
25 | Overall Screen Dimensions | 622mm*1127mm*75mm |
26 | Display Size | 600mm*800mm |
No. | Item | Technical Parameters |
|---|---|---|
1 | Pixel Composition | SMD1010 |
2 | Pixel Pitch | 1.5625mm |
3 | Module Size | 250mm*250mm |
4 | Module Resolution | 160×160 |
5 | Module Arrangement (HxV) | 2x4 |
6 | LED Packaging Manufacturer | Zhaochi |
7 | Overall Screen Resolution | 204,800 pixels per unit |
8 | Maximum White Balance Brightness | 5000cd/㎡ |
9 | Gray Scale Level | 12 bits |
10 | Aspect Ratio | 9:16 |
11 | Color Temperature | 6500-9500K |
12 | Viewing Angle | 160° |
13 | Scanning Mode | 1/40 scan |
14 | Brightness Adjustment | Automatic (built-in light sensor) |
15 | Frame Rate | 60Hz |
16 | Refresh Rate | 7680Hz |
17 | Control System | Asynchronous (Nova) |
18 | Battery Capacity | 70Ah |
19 | Input Voltage | 9V-36V |
20 | Battery Technology | CATL (Contemporary Amperex Technology Co., Limited) Ternary Lithium Blade Battery |
21 | Charging Time | 5 hours |
22 | Working Time | 10-12 hours |
23 | IP Rating | IP65 |
24 | Control Method | Wi-Fi APP, USB Disk, Ethernet, Cloud |
25 | Ambient Temperature / Humidity | Temperature: -20℃～+70℃, Humidity: 10%-95% |
26 | Display Size | 500mm(H)*1000mm(V) (43 inch) |
27 | Maintenance (Optional) | Front & Rear Maintenance |
28 | Overall Screen Weight | 55KG/unit (including battery) |
29 | Overall Screen Dimensions (VxHxT) | 1310mm*505mm*45mm (battery pack thickness: 210mm) |
No. | Item | Technical Parameters |
|---|---|---|
1 | Pixel Composition | 1 Red + 1 Green + 1 Blue LED (SMD1415) |
2 | Pixel Pitch | 1.953mm |
3 | Module Size | 250mm * 250mm |
4 | Module Resolution | 128 × 128 |
5 | Module Arrangement (H×V) | 2 × 4 |
6 | LED Packaging Manufacturer | CSOT (Common Cathode) |
7 | Whole Screen Resolution | 131072 pixels/unit |
8 | Maximum White Balance Brightness | 5000cd/㎡ |
9 | Gray Level | 12bits |
11 | Aspect Ratio | 9:16 |
12 | Color Temperature | 6500-9500K |
13 | Viewing Angle | 160° |
14 | Scanning Method | 1/32 Scan |
15 | Brightness Adjustment | Automatic (built-in light sensor) |
16 | Frame Rate | 60HZ |
17 | Refresh Rate | 7680HZ |
18 | Control System | Asynchronous (NovaStar) |
- | Battery Capacity | 70Ah |
- | Input Voltage | 9v-36v |
- | Battery Technology | CATL Ternary Lithium Blade Battery |
19 | Charging Time | 5 hours |
20 | Working Duration | 10-12 hours |
21 | Ingress Protection Rating | IP65 |
- | Control Method | Wi-fi APP, Udisk, Ethernet, Cloud |
23 | Ambient Temperature/Humidity | Temperature: -20℃～+70℃, Humidity: 10%-95% |
24 | Display Size | 500mm(H) × 1000mm(V) (43-inch) |
25 | Maintenance (Optional) | Front and Rear Maintenance |
26 | Screen Weight | 55KG/unit (including battery) |
27 | Screen Dimension (V×H×T) | 1310mm × 505mm × 45mm (battery pack thickness 210mm) |
No. | Item | Technical Parameters |
|---|---|---|
1 | Pixel Composition | 1 Red + 1 Green + 1 Blue LED (SMD1415) |
2 | Pixel Pitch | 2.3mm |
3 | Module Size | 250mm * 250mm |
4 | Module Resolution | 108 × 108 |
5 | Module Arrangement (H×V) | 2 × 4 |
6 | LED Packaging Manufacturer | CSOT (Common Cathode) |
7 | Whole Screen Resolution | 93312 pixels/unit |
8 | Maximum White Balance Brightness | 5000cd/㎡ |
9 | Gray Level | 12bits |
11 | Aspect Ratio | 9:16 |
12 | Color Temperature | 6500-9500K |
13 | Viewing Angle | 160° |
14 | Scanning Method | 1/27 Scan |
15 | Brightness Adjustment | Automatic (built-in light sensor) |
16 | Frame Rate | 60HZ |
17 | Refresh Rate | 7680HZ |
18 | Control System | Asynchronous (NovaStar) |
- | Battery Capacity | 70Ah |
- | Input Voltage | 9v-36v |
- | Battery Technology | CATL Ternary Lithium Blade Battery |
19 | Charging Time | 5 hours |
20 | Working Duration | 10-12 hours |
21 | Ingress Protection Rating | IP65 |
- | Control Method | Wi-fi APP, Udisk, Ethernet, Cloud |
23 | Ambient Temperature/Humidity | Temperature: -20℃～+70℃, Humidity: 10%-95% |
24 | Display Size | 500mm(H) × 1000mm(V) (43-inch) |
25 | Maintenance (Optional) | Front and Rear Maintenance |
26 | Screen Weight | 55KG/unit (including battery) |
27 | Screen Dimension (V×H×T) | 1310mm × 505mm × 45mm (battery pack thickness 210mm) |
