No. | Item | Technical Parameters |
|---|---|---|
1 | Pixel Composition | 1R1G1B (1212 lamp) |
2 | Pixel Pitch | 1.538mm |
3 | Module Size | 320mm*160mm |
4 | Module Resolution | 208×104 |
5 | Overall Screen Resolution | 1,038,336 pixels per unit |
6 | Maximum Brightness | 500cd/㎡ |
7 | Display Size | 1280mm*1920mm |
8 | Overall Screen Dimensions | 1280mm*1930mm*55mm |
9 | Viewing Angle | Horizontal: ≥140°; Vertical: ≥110° |
10 | Device Driving Mode | 1/52 scan |
11 | Overall Screen Weight | 33KG |
12 | Base Weight | 12KG |
13 | Playback Mode | WiFi/4G/USB |
14 | Working Voltage | AC 110V/220V±15% |
15 | Ambient Temperature and Humidity | Temperature: -20℃～+60℃; Humidity: 10%-65% |
16 | Power Consumption (Max/Average) | Approx. 500W/㎡ / Approx. 150W/㎡ |
17 | Flatness | Gap between adjacent pixels: ≤0.5mm; Module splicing gap: ≤0.5mm |
18 | Switching Power Supply | 5V/40A |
19 | Control System | Nova Asynchronous Control System |
No. | Item | Technical Parameters |
|---|---|---|
1 | Pixel Composition | 1R1G1B (1515 lamp) |
2 | Pixel Pitch | 1.86mm |
3 | Module Size | 320mm*160mm |
4 | Module Resolution | 172×86 |
5 | Overall Screen Resolution | 710,016 pixels per unit |
6 | Maximum Brightness | 500cd/㎡ |
7 | Display Size | 1280mm*1920mm |
8 | Overall Screen Dimensions | 1280mm*1930mm*58mm |
9 | Viewing Angle | Horizontal: ≥140°; Vertical: ≥110° |
10 | Device Driving Mode | 1/43 scan |
11 | Overall Screen Weight | 33KG |
12 | Base Weight | 12KG |
13 | Playback Mode | WiFi/4G/USB |
14 | Working Voltage | AC 110V/220V±15% |
15 | Ambient Temperature and Humidity | Temperature: -20℃～+60℃; Humidity: 10%-65% |
16 | Power Consumption (Max/Average) | Approx. 500W/㎡ / Approx. 150W/㎡ |
17 | Flatness | Gap between adjacent pixels: ≤0.5mm; Module splicing gap: ≤0.5mm |
18 | Switching Power Supply | 5V/40A |
19 | Control System | Nova Asynchronous Control System |
No. | Item | Technical Parameters |
|---|---|---|
1 | Pixel Composition | 1R1G1B (1515 lamp bead) |
2 | Pixel Pitch | 1.86mm |
3 | Module Size | 320mm*160mm |
4 | Module Resolution | 172×86 |
5 | Overall Screen Resolution | 710,016 pixels per unit |
6 | Maximum Brightness | 500cd/㎡ |
7 | Display Size | 1280mm*1920mm |
8 | Overall Screen Dimensions | 1280mm*1930mm*58mm |
9 | Viewing Angle | Horizontal: ≥140°; Vertical: ≥110° |
10 | Driving Mode | 1/43 scan |
11 | Overall Screen Weight | 33KG |
12 | Base Weight | 12KG |
13 | Playback Mode | WiFi/4G/USB |
14 | Working Voltage | AC 110V/220V±15% |
15 | Ambient Temperature and Humidity | Temperature: -20℃～+60℃, Humidity: 10%-65% |
16 | Power Consumption (Maximum/Average) | Approx. 500W/㎡ / Approx. 150W/㎡ |
17 | Flatness | Gap between adjacent pixels: ≤0.5mm; Module splicing gap: ≤0.5mm |
18 | Switching Power Supply | 5V/40A |
19 | Control System | Nova Asynchronous Control System |
